Foundry Crane Ladle Hook Spreader Description

The Foundry Crane Ladle Hook Spreader is a heavy-duty load balancer and spreading beam engineered specifically for molten metal ladle handling in foundry, steelmaking, and metallurgical environments. It distributes crane hook load across multiple lifting points, preventing ladle tilt, uneven stress, and rope/cable wear. It can withstand extreme heat, heavy cyclic loads, and harsh industrial conditions.

Its structure consists of hook parts, beam component, reliable connection and suspension devices. With high strength steel, it has the ability to lift over large spans, making full use of the advantages of the gantry crane to lift heavy and large-volume objects, meeting the lifting requirements of large-scale objects in industrial and construction fields. It is equipped with multiple hooks for coordinated operation, enabling the lifting of large-sized objects with irregular shapes and uneven centers of gravity, better controlling the balance and posture, and reducing the risk of lifting.

It has flexible positioning and moving capabilities, allowing for precise position adjustments in both horizontal and vertical directions. This advantage is beneficial to logistics handling and production assembly. Moreover, gantry ladle hook has high safety and reliability, with overload protection, limit switches, emergency braking and other devices.

Features of Foundry Crane Ladle Hook Spreader

Applications of Foundry Ladle Crane Hook Spreaders

• Foundry and Cast Steel Plants: Lifting and transporting molten iron, steel, and non-ferrous metal ladles
• Steelmaking and Induction Furnaces: Hoisting crucibles and melting pots during pouring operations
• Heavy Steel Fabrication: Spreading crane loads for large molds, tundishes, and heavy castings
• Shipbuilding and Heavy Industry: Lifting oversized ladles and tundishcarriers in shipyards
• Heat Treatment Facilities: Handling large-capacity heat treatment bins and molten salt baths
• Scrap Yards and Metallurgical Recycling: Moving ladles loaded with scrap metal for furnace charging

Professional Foundry Crane Ladle Hook Spreader Manufacturer

معرض دافانج

شهادة دافانج رافعة

FAQ — Frequently Asked Questions

Q1: What is the maximum load capacity of your ladle hook spreaders?

A1: Standard models range from 5 tons to 500 tons SWL. We also engineer custom spreaders beyond this range for ultra-large ladles and tundishes. All units are individually load-tested and certified before shipment.

Q2: How does this spreader handle the extreme heat from molten ladles?

A2: The spreader is constructed from heat-resistant alloy steel with optional ceramic insulation layers on contact surfaces. The design accounts for thermal expansion, and critical joints use high-temp lubricants rated above 600°C. We also offer water-cooled attachment options for the most demanding furnace environments.

Q3: Can the spreader be used with existing overhead crane systems?

A3: Yes. The spreader connects directly to standard crane hooks via its top attachment point. The bottom hooks or shackles attach to the ladle's lifting ears or trunnions. No crane modification is required. We provide rigging diagrams for safe setup.

Q4: How do I maintain the spreader in daily foundry operations?

A4: Regular inspections should include:

• (1) Visual check for cracks, deformation, and heat discoloration after each shift;
• (2) Lubrication of hinge/pivot points with high-temp grease weekly;
• (3) Measurement of hook wear and jaw opening;
• (4) Annual professional inspection and recertification by a qualified lifting engineer. Keep a maintenance log on file.

Q5: Do you offer custom designs for non-standard ladle configurations?

A5: Absolutely. Ladle shapes, trunnion positions, and lifting ear configurations vary by manufacturer. We accept CAD drawings or physical samples and can design a spreader with the exact span, attachment points, and capacity you need. Typical lead time for custom units is 3–6 weeks with engineering drawings provided for approval before production.
