الرافعة الجيبية المثبتة على الحائط من النوع BX

What Is Wall Mounted رافعة ذراع الرافعة?

Wall Mounted Jib Crane is a compact, light-duty lifting solution for workshops, warehouses, and manufacturing floors with limited space. Mounted directly onto a wall or structural column, it features a box-section boom that delivers exceptional strength and resistance to deflection. With a lifting capacity ranging from 0.5 to 1 ton, it provides precise, smooth load handling for repetitive tasks. It can also effectively eliminate manual lifting and boosting operational efficiency.

As one of the small lifting equipment, wall mounted jib crane has no requirements for ground space or special foundations. The columns supporting the horizontal ]beams are replaced by the walls provided by the factory or plant itself. It is able to rotate 180 degrees, with the lifting capacity of up to 5 tons and a boom length of up to 7 meters. This allows working in the narrowest factories, warehouses or other industrial spaces.

مثبتة بإحكام على الحائط، ولا تشغل مساحة على الأرض. تتألف من عارضة عرضية متينة وسكة حديدية ملساء وجهاز رفع، وهي سهلة التشغيل. يمكن للمستخدمين اختيار قدرة الرفع المقدرة للرفع الدقيق للمواد. مناسبة للاستخدام في المصانع والمستودعات وغيرها من المواقع، سواء كان جزءًا صغيرًا أو حمولة أثقل قليلاً، يمكن التعامل معها بسهولة لتعزيز الكفاءة التشغيلية.

Advantages of Wall-Mounted Jib Cranes

• Spece-saving Wall-Mounted Design: Does not require a ground support structure, it is ideal for space-constrained environments
• 360° Rotation: Smooth slewing across the boom's arc for flexible positioning
• Heavy-Duty Box Section Boom: Superior rigidity and load distribution, it minimizes deflection under full capacity
• مرونة عالية: مع الكابولي القابل للدوران، تغطي نطاق عمل كبير. يمكن للمستخدمين ضبط زاوية وموضع الكابولي حسب الحاجة، مما يجعلها ملائمة لإجراء عمليات مختلفة.
• تحسين كفاءة العمل: With convenient operation and wide working coverage, it can quickly and efficiently complete material handling tasks, improving work efficiency
• Easy Installation: Bolted mounting to wall or column; no special foundations needed
• Low Maintenance: Simple, robust mechanical design with minimal wearing parts
• Corrosion Resistance: Available with painted or galvanized finishes for harsh environments
• Safety First: Fixed to the wall, the risk of equipment movement or instability is reduced. Equipped with limit switches, overload protection, and emergency stop as standard

Main Application of BX Type Wall Mounted Jib Crane

The wall mounted jib crane is suitable for manufacturing workshops, warehouses, food industries, .

• Manufacturing & Assembly Lines: Lift and position components during assembly, welding, and machining operations
• Warehouses & Logistics: Load/unload pallets, move drums, and handle packaged goods
• Workshops: Support tooling, fixtures, and workpieces in fabrication and repair shops
• Food & Beverage Industry: Assist with ingredient handling and equipment maintenance where cleanliness and hygiene are critical
• Construction Sites: Light material handling in confined areas where a freestanding bridge crane won't fit

بالنسبة للمساحة المحدودة، فإنها تستخدم بذكاء التثبيت على الحائط، ولا تشغل مساحة على الأرض، وتحقق رفع المواد ونقلها بشكل مريح. الرافعة الجيبية المثبتة على الحائط هي معدات عملية لمناولة المواد.

المعايير الفنية

قدرة الرفع (ر)		0.25			0.5			1
ارتفاع الرفع (م)		5	5.5	6	5	4.5	6	5	5.5	6
نصف القطر الصالح (م)		4	4.5	5	4	4.5	5	4	4.5	5
نظام العمل		A3
سرعة الرفع	سرعة بطيئة (م/دقيقة)	0.8
	السرعة العادية (م/دقيقة)	8
سرعة الدوران (م/دقيقة)		20
زاوية الدوران		180°
ارتفاع المركز (م)		1.2			1.6			2.56
أقصى طول (م)		4.326	4.826	5.326	4.430	4.930	5.430	4.525	5.025	5.525
الوزن الإجمالي (كجم)		343	362	378	389	405	420	768	782	810

الشركة المصنعة للرافعة الجيبية الاحترافية المثبتة على الحائط

شهادة دافانج رافعة

Frequently Asked Questions (FAQ)

Q1: What is the maximum outreach available for this cantilever jib crane?

A: Standard outreach ranges from 3 meters up to 8 meters depending on the model and lifting capacity. Custom lengths can be engineered to match your specific spatial requirements.

Q2: Can the wall mounted jib crane rotate a full 360°?

A: Yes. The jib boom supports continuous 360° rotation (or 270° if the wall bracket design limits full rotation). Precise rotation lock and smooth brake control are provided for safe operation.

Q3: What power source is required?

A: The jib crane uses an electric chain hoist as standard. It requires standard 3-phase 380V/50Hz (or local voltage on request). Pneumatic and manual chain hoist options are also available.

Q4: How do I select the right model for my application?

A: Consider three key factors: (1) maximum load weight (up to 1 ton), (2) required outreach distance, and (3) the structural integrity of the wall/column it will be mounted to. Our technical team can provide a mounting consultation to confirm suitability.

Q5: What maintenance is required for this jib crane?

A: The Box Type Wall Mounted Jib Crane is designed for minimal maintenance. We recommend quarterly inspections of the mounting bolts, slewing mechanism, and chain hoist. Lubrication points are clearly marked. Annual professional inspections are advised for safety compliance.
